Fire Suppression System

Fire Suppression System Specification

Features
Fast response, non-conductive, no residue, environment-friendly

Operating Pressure
25 Bar (360 psi)

Fire Class
Class A, B, C & Electrical Fires

Control Type
Automatic and Manual

Coverage Area
Up to 200 sq. meters per unit (subject to configuration)

Mounting Type
Wall or Ceiling Mounted

Shape
Cylindrical

Connectivity Type
Wired panel interface, relay outputs

Voltage
24V DC (for detection and control unit)

Coating Type
Powder Coated Exterior

Fire Extinguisher Type
Clean Agent Modular Fire Suppression

Installation Type
Direct (Ceiling or Panel Mounted)

Technology
Clean Agent Gas-based (FM-200, Novec 1230, or equivalent)

Energy Efficiency Rating
High (no power required for agent operation)

Working Temperature
0C to 55C

Application
Industrial, Commercial, Data Centers, Server Rooms, Electrical Panels

Max Flow Rate
Up to 100 L/min

Diameter
Varies (customizable based on requirement)

Capacity
5 kg to 50 kg (cylinder options)

Pressure
2.5 MPa (standard for clean agent systems)

Discharge Time
Less than 10 seconds full discharge

Transportation/Storage
Safe for transport under pressurized conditions

Alarm Integration
Compatible with existing fire alarm panels

Cylinder Material
Seamless steel

Detection System
Linear heat sensing or smoke detection

Noise Level
Below 70 dB at discharge

Refillable
Yes (serviceable cylinders)

System Certification
UL Listed, CE Approved

Life Expectancy
Over 10 years

Agent Discharge Range
High nozzles coverage up to 15 meters

Fire Suppression System Trade Information

Minimum Order Quantity
5 Kits

Supply Ability
100 Kits Per Month

Delivery Time
2-10 Days

Fire Suppression System About

Grab a sizzling bargain with this top-tier Fire Suppression System-an enviable addition to your industrial, commercial, or data center setup. Engineered with lustrous seamless steel cylinders, this system ensures fast response with full discharge in under 10 seconds. Enjoy peace of mind with UL and CE certification, over 10 years' life expectancy, and refillable, serviceable cylinders. Get unbeatable energy efficiency, high coverage (up to 200 sq. meters per unit), environment-friendly clean agent technology, and seamless integration with existing alarm panels at an extraordinary discount. Safe, non-conductive, and dust-free protection-all at a price worth fighting for.

Ideal Applications and Surfaces

This Fire Suppression System is expertly crafted for application on electrical panels, server rooms, control rooms, commercial premises, and data centers. It is suitable for industrial and commercial use, and can be mounted directly to ceilings or walls. The application method is straightforward-either automatic detection (via smoke or linear heat sensing) or manual discharge through a control unit. Its clean agent gas-based technology protects sensitive equipment without leaving any residue, making it a must-have for modern environments.

Sample Policy, Export Markets, and Packaging

We offer a transparent sample policy-sampling charges may apply-allowing clients to evaluate performance before a full order. Order processing is swift, ensuring prompt delivery. Our main export markets include Asia, the Middle East, and Africa. Goods transport is handled with precision, using robust packaging (high-strength boxes, shock-absorbing materials) to ensure safe arrival of your system. Each order is processed with meticulous care, maintaining the integrity and function of the Fire Suppression System.

FAQ's of Fire Suppression System:

Q: How does the Fire Suppression System detect and suppress fires?

A: The system utilizes linear heat sensing or smoke detection to automatically sense a fire and discharge the clean agent gas. It can also be activated manually. The suppression agent is released within 10 seconds, delivering a rapid response to extinguish Class A, B, C, and electrical fires.

Q: What are the main benefits of using this Fire Suppression System in data centers or server rooms?

A: This system offers non-conductive, residue-free, and environment-friendly fire suppression that won't damage sensitive electronics. Its high-coverage nozzles and fast activation protect vital equipment and reduce downtime dramatically.

Q: Where can the Fire Suppression Cylinder be installed?

A: The cylinder is customizable in diameter and capacity and can be mounted directly on ceilings or walls. Its flexibility makes it suitable for server rooms, control panels, commercial spaces, and large industrial environments.

Q: What is the process for refilling and maintaining the cylinders?

A: Serviceable and refillable cylinders allow easy maintenance. After agent discharge or periodic inspection, simply contact your authorized dealer or service provider for prompt refilling and inspection, ensuring the system remains in top operational condition.

Q: How does the system integrate with existing fire alarm panels?

A: It's designed for seamless connectivity, featuring a wired panel interface and relay outputs to communicate with current fire alarm systems, guaranteeing continuation of established safety protocols.

Q: What is the expected operational lifespan and efficiency of the system?

A: With a robust, powder-coated seamless steel cylinder and advanced clean agent technology, the system has a life expectancy of over 10 years and does not require electrical power for agent operation, ensuring high energy efficiency and long-term reliability.
