Fire Resistance Glass

Fire Resistance Glass Specification

Fire Class
Class E, EW, EI (as per EN 13501-2 Standard)

Product Type
Glass Block Sheet Glass

Coverage Area
Varies based on installation

Technology
Multi-layer laminated glass with intumescent interlayers

Features
High fire resistance, Integrity and insulation, Transparent, UV Stable

Working Temperature
Up to 1200C short term exposure

Shape
Flat panel (custom shapes available)

Coating Type
Optional low-E or UV protective

Mounting Type
Framed or structural bonded

Installation Type
Frame mounting, Partition or window installation

Energy Efficiency Rating
Improved due to insulating interlayers

Control Type
Passive fire protection

Application
Fire protection for buildings, doors, partitions and windows

Diameter
Customizable as per requirement

Environmental Resistance
UV stable, moisture resistant interlayers

Edge Finish
Polished or as specified

Fire Resistance Duration
30, 60, 90, 120, or 180 minutes

Sound Insulation
High acoustic performance due to laminated construction

Glass Types
Clear, Wired, Laminated, Tempered

Light Transmission
Up to 80% (depending on configuration)

Standards Complied
EN 1363-1, EN 1364-1, EN 13501-2

Thickness
Typically 6mm to 60mm (as per fire-rating requirements)

Fire Resistance Glass Trade Information

Minimum Order Quantity
20 Pieces

Supply Ability
100 Pieces Per Month

Delivery Time
2-10 Days

Fire Resistance Glass About

Fire Rated Glass is a type of glass that is designed to resist the spread of fire and smoke. It is a highly specialized product that is used in many commercial and residential buildings to provide a safe, fire-resistant barrier between rooms. Fire Rated Glass is available in a variety of shapes, sizes, and thicknesses to meet the needs of any application. The glass is usually made of a combination of two or more layers of glass, with an inner layer of fire-resistant material. The outer layer is typically a clear or tinted glass that provides a visual barrier. Fire Rated Glass is also available in a variety of finishes, such as acid etched, heat reflective, and coated glass.

Superior Multi-Layer Technology

Engineered with multiple laminated layers and intumescent interlayers, this fire resistance glass provides both integrity and insulation, actively expanding under heat to seal off flames, heat, and smoke. The advanced construction also results in excellent sound insulation and durability, making it a reliable choice for commercial and residential use.

Customizable for Versatile Applications

Fire resistance glass is available in custom thicknesses (6mm-60mm), diameters, and shapes. Whether installed in doors, partitions, or windows, its configuration can be tailored to specific fire ratings (30-180 minutes) and architectural requirements. Different mounting options such as frame mounting and structural bonding ensure seamless integration in various building designs.

Tested to International Standards

Fully compliant with EN 1363-1, EN 1364-1, and EN 13501-2, the glass meets stringent European fire safety regulations. Fire classes E, EW, and EI guarantee different levels of performance for integrity, insulation, and radiance control. UV stability and moisture resistance make it suitable for both interior and exterior applications in diverse climates.

FAQ's of Fire Resistance Glass:

Q: How does fire resistance glass provide fire protection?

A: Fire resistance glass utilizes multi-layer laminated construction with intumescent interlayers that expand under high temperatures. This mechanism forms a heat barrier, containing fire, smoke, and hot gases, and helps maintain integrity and insulation for a specified duration, such as 30, 60, 90, 120, or 180 minutes.

Q: What are the different thicknesses and fire ratings available for fire resistance glass?

A: This glass is available in thicknesses from 6mm up to 60mm, chosen according to the required fire resistance duration-30, 60, 90, 120, or 180 minutes-based on building codes and safety needs.

Q: Where can fire resistance glass be installed?

A: Fire resistance glass is suitable for use in buildings, particularly in doors, partitions, windows, and facades that require fire protection. Its versatility makes it ideal for both commercial and residential projects.

Q: What benefits does fire resistance glass offer besides fire protection?

A: Besides robust fire safety, the glass delivers up to 80% light transmission, high acoustic insulation due to its laminated design, UV stability, improved energy efficiency, and aesthetic transparency while maintaining strength.

Q: When should I use Class E, EW, or EI fire resistant glass?

A: You should specify the fire class depending on your application's requirements: Class E provides integrity, EW adds limited radiation control, and EI ensures both integrity and insulation. The classification is as per EN 13501-2 standards.

Q: How is fire resistance glass installed and maintained?

A: It can be mounted in frames or bonded structurally as part of building partitions or windows. Proper installation by professionals ensures optimal fire performance, and minimal maintenance is needed due to its durable, moisture-resistant, and UV-stable composition.

Q: What customization options are available for fire resistance glass?

A: The product can be customized in shape, diameter, thickness, edge finish (such as polished), and can include optional low-E or UV protective coatings to match specific project requirements and aesthetic preferences.
