Road Stud

Road Stud Specification

Mounting Type
Surface Mount

Features
High Reflectivity, Durable Body, Night Visibility

Installation Type
Surface Mount / Epoxy Fixing

Control Type
Fixed

Coating Type
Acrylic / UV Resistant Paint

Shape
Rectangular with Raised Profile

Color
Yellow And Red

Coverage Area
Per stud: typically 100-150 cm2

Technology
Reflective / Cat Eye

Connectivity Type
Non-electric / Passive

Working Temperature
-20C to 60C

Application
Road Safety, Lane Delineation

Diameter
100 mm

Pressure
Up to 30 Tons

Color
Yellow (body), White/Red Reflectors

Reflective Panel
Dual sided

Dimensions
100 mm x 100 mm x 20 mm (LxWxH)

Life Span
3 to 5 years

Material
ABS Plastic / Polycarbonate / Aluminum Base

Reflector Type
Polycarbonate Reflective Lens

Weight
120 - 200 grams

Load Capacity
Up to 30,000 kg

Conformity Standards
ASTM D4280 / EN 1463-1

Water Resistance
Yes, IP65 Rated

Road Stud Trade Information

Minimum Order Quantity
20 Pieces

Supply Ability
100 Pieces Per Month

Delivery Time
2-10 Days

About Road Stud

Road stud is made of ABS material and designed to bear maximum load.
High reflective reflectors molded in PMMA material are fitted on the stud.
The reflectors are welded with a ABS base plate through ultrasonic welding process.

Superior Night Visibility and Safety

Equipped with premium polycarbonate reflective lenses on both sides, this road stud ensures excellent night visibility. Its raised rectangular profile and high-reflectivity design help drivers easily identify lanes, especially in low-light or adverse weather conditions. Dual-sided reflectors maximize effectiveness by illuminating from multiple angles, distinctly marking road boundaries and enhancing overall road safety.

Robust Construction and Long-Lasting Performance

Manufactured from sturdy materials like ABS plastic, polycarbonate, or aluminum, the road stud boasts a load capacity of up to 30,000 kg. It withstands heavy traffic and pressure while maintaining its shape and reflectivity. The acrylic or UV-resistant paint coating protects against wear, ensuring continued performance and longevity for 3 to 5 years-even in challenging Indian climates.

Easy Installation and Versatile Application

Designed for hassle-free surface mounting or epoxy fixing, the road stud requires no electrical connectivity, making it a versatile and cost-effective solution. Its IP65-rated water resistance and robust construction allow installation on highways, city roads, parking lots, and other high-traffic areas-perfect for lane delineation and pedestrian safety applications.

FAQ's of Road Stud:

Q: How is this road stud installed on the road surface?

A: The road stud can be installed using surface mounting or epoxy fixing methods. Clean the installation area, apply epoxy adhesive, and press the stud firmly onto the surface. Allow appropriate curing time before exposing it to traffic.

Q: What benefits does this road stud offer for road safety?

A: It provides high visibility at night and in adverse weather, aids lane delineation, and helps prevent accidents. The durable and reflective design ensures optimal guidance for drivers, improving overall safety on highways and urban roads.

Q: What materials make up the body of the road stud?

A: The body is constructed from ABS plastic, polycarbonate, or aluminum, chosen for their durability, impact resistance, and ability to withstand extreme temperatures and heavy loads.

Q: When should these road studs be used for best effectiveness?

A: They are ideal for use in situations requiring enhanced night visibility, under low-light conditions, during fog, or in locations with high traffic volume to delineate lanes and mark hazardous zones.

Q: Where can these road studs be applied?

A: These road studs are suitable for highways, city roads, parking spaces, intersections, and pedestrian areas to provide clear lane demarcation and ensure pedestrian and vehicular safety.
